The Complete Guide to Infrared Electrical Inspections

An infrared electrical inspection uses thermographic cameras to capture heat signatures emitted by electrical components under load. Unlike traditional inspections that rely on visual observation and manual testing, infrared surveys can non-invasively detect temperature variations that indicate faults, imbalances, or overloads — all while equipment remains fully energized.

How Infrared Cameras Work

Modern thermal cameras detect electromagnetic radiation in the 8–14 micron wavelength range — the far-infrared spectrum — and convert it into a visual temperature map called a thermogram. Certified thermographers interpret these images using emissivity corrections, ambient temperature baselines, and load conditions to classify defects by severity.

What a Standard Inspection Covers:

• Main distribution panels, sub-panels, and transfer switches

• Switchgear and motor control centers (MCC)

• Transformers (dry-type and liquid-filled)

• Bus ducts and cable trays

• UPS systems and battery banks

• HVAC electrical components

• Lighting distribution systems

Understanding Your Inspection Report

A professional thermographic report includes thermal images paired with visual photographs of each defect site, measured temperatures, emissivity settings, ambient conditions, and a severity classification. Anamik Electric Corp classifies findings using a three-tier severity system aligned with NETA MTS standards: Priority 1 (immediate action), Priority 2 (action within 30 days), and Priority 3 (monitor and schedule).

Preparing Your Facility for an Inspection

• Ensure all panels and equipment are under normal operating load (minimum 40% load)

• Provide access to all electrical rooms and equipment areas

• Notify tenants or operations teams of inspection timing

• Have as-built electrical drawings available if possible

• Clear obstructions from panel fronts and equipment enclosures

Ready to schedule your infrared inspection? Anamik Electric Corp serves Broward and Miami-Dade counties with flexible scheduling and detailed reporting. Most inspections are completed in a single visit, with reports delivered within 48 hours.
